SYNTRON 4DOF Servo Actuator Kit – 4×750W TA16A Actuators with Motion Controller (150mm Stroke, 127kg Load)

The SYNTRON 4DOF Servo Actuator Kit is a powerful and reliable motion system designed for dynamic simulation platforms, industrial robotics, and automation projects. Engineered for precision and high performance, this kit includes four synchronized servo motor actuators, offering seamless four-degree-of-freedom (4DOF) motion control.

Each actuator features the robust TA16A model with a 150mm stroke, supporting a maximum load of 127 kg and delivering top speeds of 500mm/s thanks to its efficient 1610 lead screw and 1:1 ratio. The actuators are driven by 750W servo motors rated at 3000RPM and 2.39N·m torque, ensuring quick response and smooth motion.

The system is completed with four matching 220V 3A servo drivers and a fully integrated motion controller box for simplified setup and reliable synchronization of all axes.

Whether you're building a professional-grade motion simulator, automated test bench, or custom robotic application, this 4DOF actuator kit provides a complete and scalable solution for real-time, high-precision motion.

Kit Includes:

• 4× Servo Motor Actuators (TA16A)

  • Stroke: 150mm

  • Max Load: 127 kg

  • Max Speed: 500mm/s

  • Lead Screw: 1610

  • Ratio: 1:1

• 4× Servo Motors

  • Power: 750W

  • Speed: 3000 RPM

  • Torque: 2.39 N·m

• 4× 220V 3A Servo Drivers

• 1× Motion Controller Box (Complete Set)

Key Features:

• Four-axis DOF motion for dynamic applications

• High torque and high-speed performance

• Complete with drivers and control system

• Suitable for simulators, automation, and robotics

• Plug-and-play design for easy integration
